Product Details
| Weight | 580g/sqm | Width | 1000mm 1520mm |
|---|---|---|---|
| Thickness | 0.43mm | Color | Grey |
| Weave | 4H Satin | Temperature Resistance /Working Temperature | 550℃ 1000℉ |
| Coated | PTFE One Side | Fiberglass | E-glass |
| Highlight | ptfe coated fiberglass cloth,ptfe coated glass fabric | ||
Product Description
Chemical Resistant PTFE Coated Fiberglass Fabric 0.43mm Flame Resistant Barrier
Introduce
GF430P-PTFE133-8003 is 430g E-glass basic glassfiber coating with 150g PTFE single side. It's weight and thickness are suitable for many applications.
Advantage
GF430P-PTFE133-8003 is 0.43mm in thickness at a middle level PTFE Coated Fiberglass Fabric, felt hard and convient to cutting and sewing. PTFE membrane has good abrasion resistance, so can be used in movable parts.
It's can bear temperature up to 300℃. It also has property of anti-stastic.
Data
Weight | 580 g/m2 |
Thickness | 0.43 mm |
Width | 1000mm 1520mm 1550mm 2000mm |
Coated | PTFE |
Color | Grey |
Fire resistance | Good |
Working temperature | Basic fabric 550 ℃, PTFE coating 330 ℃. |
Weave | 4H Satin |
Yarn warp | EC9 136 1*0 |
Yarn weft | EC9 136 1*0 |
Construction warp | 18 ends/cm |
Construction weft | 12.6 ends/cm |
Fiberglass | E-Glass |
Applications
GF430P-PTFE133-8003 PTFE Coated Fiberglass Fabric can be used in many industry, just like ship building, chemical material stock, heat insulation and air distribution. We use it make dust Lagging, smoke curtain, reusable thermal insulation jacket and thermal insulation pad.
